טיימר Z1T-M5

דגם: Z1T-M5

מק"ט: 2.61018 קטגוריות: ציוד ללוחות, ציוד מיתוג ללוח, קוצבי זמן (טיימרים), תזמון ובקרה לפס דין/פנל

קוצב זמן (טיימר) רב תחומי ורב מתחי, בעל 5 פונקציות שונות ו-2 תחומי זמן (תלויים אחד בשני). רמת דיוק ואמינות גבוהה ביותר. מאפשר שימוש כטיימר חד תכליתי סטנדרטי ואף כטיימר מחזורי א-סימטרי או סימטרי.

יישומים

להתקנה על פס דין
לשליטה ותזמון מערכות חשמליות

הוסף לסל

מפרט טכני

כללי

מספר פונקציות	5
טווח זמן 1 לכיול	0.1ש'-10יממות
טווח זמן 2 לכיול	0.1ש'-10יממות (נגזרת של בחירת זמן 1)
ברגים	M6 שטוח
מתח הזנה	10%± 12-240VAC/DC
ממסר	250VAC /10A/ 1250VA
מיתוג מקסימלי	10A
זרם ממסר AC (עבור מגע פתוח)	10A/1250VA
זרם ממסר DC (עבור מגע פתוח)	5A/150W
צריכה עצמית AC	<5VA
צריכה עצמית DC	<1.5W
זמן אתחול פעולה	100MS מקסימום
תדר	45-65Hz
חיזוק ברגים (Nm)	0.5Nm
כניסות מוליכי הזנה (ממ"ר)	2.5mm² / 14AWH
חתך חישוף הזנה (מ"מ)	8mm-9mm
דרגת אטימות	IP20
לחות סביבתית	95%
טמפרטורה עבודה (ºC)	20+60Cº –
אורך חיים מכאני (מחזורים)	≥ 10⁷
כמות במארז	1 יח'

פונקציות

ND	השהייה בהפעלה
FD	השהייה בניתוק
NFD	השהייה בהפעלה + השהייה בניתוק
NDF	מחזורי א-סימטרי הפעלה תחילה
FDF	מחזורי א-סימטרי ניתוק תחילה

מידות (מ"מ)

משקל

60גר'

תקנים
